Vertical Scrolling of Live Streams

bgView = UIImageView(frame: self.view.bounds)
// The image should be the placeholder image for the corresponding live streaming room. Business personnel should obtain the image in advance.
bgView.image = UIImage(named: "1.png")
bgView.contentMode = .scaleAspectFill
bgView.translatesAutoresizingMaskIntoConstraints = false
self.view.insertSubview(bgView, at: 0)

NSLayoutConstraint.activate([
    bgView.topAnchor.constraint(equalTo: view.topAnchor),
    bgView.bottomAnchor.constraint(equalTo: view.bottomAnchor),
    bgView.leadingAnchor.constraint(equalTo: view.leadingAnchor),
    bgView.trailingAnchor.constraint(equalTo: view.trailingAnchor),
])

DispatchQueue.main.async {
    UIView.transition(
            with: self.bgView,
            duration: 0,
            options: .transitionCrossDissolve,
            animations: {
                // Business personnel switches the corresponding placeholder image.
                self.bgView.image = UIImage(named: strRoomId)
            }, completion: nil)
}

let src = TRTCSwitchRoomConfig()
// Generate the corresponding room ID and room entry credential according to business needs. In this example, generate the room entry credential on the client. For online businesses, obtain the information from the backend.
src.strRoomId = strRoomId
src.userSig = GenerateTestUserSig.genTestUserSig(identifier: userId) as String
trtcCloud.switchRoom(src)

// Pull video streams.
func onUserVideoAvailable(_ userId: String, available: Bool) {
    if available {
        trtcCloud.startRemoteView(userId, streamType: .big, view: view)
    } else {
        trtcCloud.stopRemoteView(userId, streamType: .big)
    }
}

// When the first video frame starts rendering, switch the placeholder image to the background and display the video.
func onFirstVideoFrame(_ userId: String, streamType: TRTCVideoStreamType, width: Int32, height: Int32) {
    // Adjust the sequence of the background image and the video rendering control as needed.
    self.view.exchangeSubview(at: 1, withSubviewAt: 0)
}

import Foundation
import ObjectiveC
import TXLiteAVSDK_Professional

@objc protocol SubCloudHelperDelegate : NSObjectProtocol {
    @objc optional func onUserVideoAvailableWithSubId(subId: Int, userId: String, available: Bool)
}

class SubCloudHelper:NSObject,TRTCCloudDelegate {
    var trtcCloud: TRTCCloud!
    var subId: Int!
    weak var delegate : SubCloudHelperDelegate? = nil

    func initWithSubId(subId: Int, trtcIns: TRTCCloud) {
        self.subId = subId
        self.trtcCloud = trtcIns
        self.trtcCloud.addDelegate(self)
    }

    func getCloud()->TRTCCloud {
        return trtcCloud
    }

    func onUserVideoAvailable(_ userId: String, available: Bool) {
        if self.delegate?.onUserVideoAvailableWithSubId?(subId: subId, userId: userId, available: available) == nil {
            return
        }
    }
}

let trtcCloud = TRTCCloud()
let subCloudHelper = SubCloudHelper()

override func viewDidLoad() {
    super.viewDidLoad()

    subCloudHelper.initWithSubId(subId: 0, trtcIns: trtcCloud.createSub())
    subCloudHelper.delegate = self
}

private var atRoom: Bool = false

var pageViewController: UIPageViewController!
var pageZero: UIViewController!
var pageOne: UIViewController!
var pageTwo: UIViewController!
var pages: [UIViewController] = []

var curPageIdx = 0
var curIsSub = false


func setupPages() {
    pageViewController = UIPageViewController(
        transitionStyle: .scroll,
        navigationOrientation: .vertical
    )
    pageViewController.dataSource = self
    pageViewController.delegate = self
    addChild(pageViewController)
    view.addSubview(pageViewController.view)
    pageViewController.didMove(toParent: self)

    // pages
    pageZero = UIViewController()
    pageZero.view.backgroundColor = .black
    pageOne = UIViewController()
    pageOne.view.backgroundColor = .black
    pageTwo = UIViewController()
    pageTwo.view.backgroundColor = .black
    pages = [pageZero, pageOne, pageTwo]

    pageViewController.setViewControllers([pages[curPageIdx]], direction: .forward, animated: false)
}

// Obtain the next/previous page.
func getShowPage(isNext: Bool) -> UIViewController {
    var newPageIdx = 0
    if isNext {
        newPageIdx = curPageIdx + 1
    } else {
        newPageIdx = curPageIdx - 1
    }
    if newPageIdx >= pages.count {
        newPageIdx = 0
    } else if newPageIdx < 0 {
        newPageIdx = pages.count - 1
    }
    return pages[newPageIdx]
}

extension RtcDuplexVC: UIPageViewControllerDataSource {
    func pageViewController(_ pageViewController: UIPageViewController, viewControllerBefore viewController: UIViewController) -> UIViewController? {
        return getShowPage(isNext: false)
    }

    func pageViewController(_ pageViewController: UIPageViewController, viewControllerAfter viewController: UIViewController) -> UIViewController? {
        return getShowPage(isNext: true)
    }
}

// The primary instance enters the room.
// Replace sdkAppId, roomID, strRoomId, userId, and userSig based on actual business needs.
// In this example, generate userSig on the client. For online businesses, obtain the information from the backend.
let params = TRTCParams()
params.sdkAppId = UInt32(SDKAppID)
params.roomId = 0
params.strRoomId = strRoomIdLst.first ?? "1"
params.userId = userId
params.role = .anchor
params.userSig = GenerateTestUserSig.genTestUserSig(identifier: userId) as String
trtcCloud.addDelegate(self)
trtcCloud.enterRoom(params, appScene: .LIVE)

// The sub-instance preloads and enters the next room.
// Replace sdkAppId, roomID, strRoomId, userId, and userSig based on actual business needs.
// In this example, generate userSig on the client. For online businesses, obtain the information from the backend.
let subParams = TRTCParams()
subParams.sdkAppId = UInt32(SDKAppID)
subParams.roomId = 0
subParams.strRoomId = strRoomIdLst[1]
subParams.userId = userId
subParams.role = .anchor
subParams.userSig = GenerateTestUserSig.genTestUserSig(identifier: userId) as String
subCloudHelper.trtcCloud.enterRoom(subParams, appScene: .LIVE)
subCloudHelper.trtcCloud.muteAllRemoteAudio(true)

func getPageByIdx(isNext: Bool) -> UIViewController {
    var newPageIdx = curPageIdx
    if isNext {
        newPageIdx += 1
    }
    if newPageIdx >= pages.count {
        newPageIdx = 0
    }
    return pages[newPageIdx]
}

extension RtcDuplexVC: TRTCCloudDelegate {
    func onUserVideoAvailable(_ userId: String, available: Bool) {
        if available {
            trtcCloud.startRemoteView(userId, streamType: .big, view: getPageByIdx(isNext: curIsSub).view)
        } else {
            trtcCloud.stopRemoteView(userId, streamType: .big)
        }
    }
}
extension RtcDuplexVC: SubCloudHelperDelegate {
    func onUserVideoAvailableWithSubId(subId: Int, userId: String, available: Bool) {
        if available {
            subCloudHelper.trtcCloud.startRemoteView(userId, streamType: .big, view: getPageByIdx(isNext: !curIsSub).view)
        } else {
            subCloudHelper.trtcCloud.stopRemoteView(userId, streamType: .big)
        }
    }
}

func updateCurRoomIdx(isNext: Bool) {
    if isNext {
        curRoomIdx += 1
        if curRoomIdx >= strRoomIdLst.count {
            curRoomIdx = 0
        }
    } else {
        curRoomIdx -= 1
        if curRoomIdx < 0 {
            curRoomIdx = strRoomIdLst.count - 1
        }
    }
}
// Here, you need to switch the room ID based on the actual business logic.
func updateNewRoom(isNext: Bool) {
    var newRoomIdx = 0
    if isNext{
        newRoomIdx = curRoomIdx + 1
    } else {
        newRoomIdx = curRoomIdx - 1
    }
    if newRoomIdx >= strRoomIdLst.count {
        newRoomIdx = 0
    } else if newRoomIdx < 0 {
        newRoomIdx = strRoomIdLst.count - 1
    }
    let newRoomStrId = strRoomIdLst[newRoomIdx]

    let src = TRTCSwitchRoomConfig()
    src.strRoomId = newRoomStrId
    src.userSig = GenerateTestUserSig.genTestUserSig(identifier: userId) as String
    if curIsSub {
        trtcCloud.switchRoom(src)
        trtcCloud.muteAllRemoteAudio(true)
    } else {
        subCloudHelper.trtcCloud.switchRoom(src)
        subCloudHelper.trtcCloud.muteAllRemoteAudio(true)
    }
}

extension RtcDuplexVC: UIPageViewControllerDelegate {
    func pageViewController(
        _ pageViewController: UIPageViewController,
        didFinishAnimating finished: Bool,
        previousViewControllers: [UIViewController],
        transitionCompleted completed: Bool
    ) {
        if completed {
            guard let currentVC = pageViewController.viewControllers?.first else {return}
            if let index = pages.firstIndex(of: currentVC) {
                // Obtain the basis for determining whether the user scrolled up or down.
                let iden = index - curPageIdx
                // Update the index of the currently displayed page.
                curPageIdx = index
                // Scroll down.
                if iden == 1 || iden == -2 {
                    // Update the index of the current room.
                    updateCurRoomIdx(isNext: true)
                    // Update the instance of the currently displayed page.
                    curIsSub.toggle()
                    // Update the room.
                    updateNewRoom(isNext: true)
                }
                // Scroll up.
                if iden == -1 || iden == 2 {
                    // Update the room.
                    updateNewRoom(isNext: false)
                    // Update the index of the current room.
                    updateCurRoomIdx(isNext: false)
                    // Update the instance of the currently displayed page.
                    curIsSub.toggle()
                    trtcCloud.muteAllRemoteAudio(true)
                    subCloudHelper.trtcCloud.muteAllRemoteAudio(true)
                }
                // Unmute the current room.
                if curIsSub {
                    subCloudHelper.trtcCloud.muteAllRemoteAudio(false)
                } else {
                    trtcCloud.muteAllRemoteAudio(false)
                }
            }
        }
    }
}
